4535 611 98931 iE33 Service Manual Page 128
CSIP Level 1 Installation: Connectivity Information
Archive Devices, Storage Commit, and Structured Report Devices
➤ To select an archive device, storage commit, or structured report device
1. Press Setups on the keyboard.
2. Click Print/Network.
3. Click the Device Selection tab.
4. Click Archive.
5. Enable the archive server or servers by selecting the check-box to the left of each server
name.
NOTE A maximum of three archive servers may be selected from the list.
6. Select a storage commit server (if configured) from the Commit Server combo box. If a
commit server is selected, also select the archive system being monitored from Ta r g et
Archive Server combo box.
7. Select a report server (if configured) from Structured Report Server combo box.
Modality Worklist and Performed Procedure Step Servers
➤ To select a worklist or performed procedure step server
1. Press Setups on the keyboard.
2. Click Print/Network.
3. Click the Device Selection tab.
4. Click Worklist.
