Xerox WorkCentre 6505 Service Manual

2-48 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Theory of Operation
s6500-061s6500-061
Paper Feed Drive
Imaging Unit
Main Drive
Gear P2
Gear P3
Gear P4
Gear P5
Feed Gear
[ Feed Roller ]
Registration Feeder Chute
Registration Clutch
[ Registration Roller ]
Rubber Registration Gear
Metal Registration Gear
[ Metal Registration Roller ]
Feed Solenoid
Imaging Unit
Gear 2
[ Drum (M) ]
[ Drum (Y) ]
Imaging Unit
Gear 1
Imaging Unit
Gear 2
[ Drum (K) ]
[ Drum (C) ]
Transfer Belt
Gear T4
Drive Gear
[ Belt ]
: Indicates The Engagement Of Gears
Front
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
