Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 2-47
Theory of Operation
Drive
Main Drive Assembly
The Main Drive transmits power as shown in the following diagram.
s6500-060
Main Drive
[ Belt ]
Transfer Belt
Gear P3
Paper Feed Drive
Registration Feeder Chute
Registration Clutch
Rubber Registration Gear
Metal Registration Gear
Gear P2Gear T4
Gear P4
Gear P5
[ Registration Roller ]
[ Metal Registration Roller ]
Feed GearFeed Solenoid
Drive Gear
[ Feed Roller ]
Drum (K)
Drum (C)
Imaging Unit Gear 2
Drum (M)
Drum (Y)
Imaging Unit Gear 2
Imaging Unit Gear 1
Imaging Unit
