Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-31
Wiring
SFP HVPS
MCU Board
PL8.2.13
P/J16
1
2
3
4
5
6
7
8
HVPS
PL4.1.19
HVPS Harness Assembly
PL9.1.5
P/J161
CF
DF-K
TR-K
TR-C
TR-M
TR-Y
BCR
BTR
BTR : Bias Transfer Roller
BCR : Bias Charge Roller
Developer
DB-C
DB-M
DB-Y
10
9
8
7
6
5
4
3
TR MON
NC
HV DO
HV LD
HV CLK
+3.0V REF
SG
9
10
2
1
MAIN CLK
SG
I/L +24V
s6500-46
K
C
M
Y
+3.0V REF
+24VDC

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
