Xerox WorkCentre 6505 Service Manual

10-30 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
SFP Xerographics
MCU Board
PL8.2.13
P/J42
5
6
7
8
9
10
PHD XPRO Harness Assembly
PL9.1.11
Humidity Harness Assembly
PL9.1.6
Imaging Unit
PL4.1.21
P/J422
6
5
4
3
2
1
+3.3VLD
DATA
CLOCK
+3.3VDC
SG
+3.3VDC
CLOCK
DATA
SG
+3.3VLD
1
2
3
4
PHD
EEPROM
P/J144
4
3
2
1
SG
+5VDC
HUMI.
TEMP.
P/J20
1
2
3
4
P/J201
4
3
2
1
EEPROM Board
PL8.2.16
Humidity
Sensor
PL8.2.7
LVPS Main Harness Assembly
PL9.1.3
ERASE Y/M/C ON (L) +3.3VDC
ERASE K ON (L) +3.3VDC
+3.3VDC
P/J14
15
16
17
P/J141
3
2
1
Erase LED
Assembly
PL4.1.8
1
2
3
4
Left Side Harness Assembly
PL3.1.18
Transfer Assembly
PL6.1.7
5
4
3
2
1
+5VDC
ADC SENSOR
LED REM
ADC V MONI
5
1
2
3
4
5
SG
P/J2811P/J281P/J28
5
4
3
2
1
ADC Sensor
s6500-461
+3.3VDC
+3.3VDC
+5VDC
+5VDC
to ROS
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
