Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-95
Error Messages and Codes
IOT Tray1 Misfeed JAM
Applicable Error Code
• 071-100
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Cassette Assy 250 (PL2.1.1)
■ Separator Holder Assy (PL2.1.5)
■ Drive Clutch and Regi Bearing Kit
(PL3.1.97)
■ Feed Solenoid Kit (PL3.1.99)
■ Left Side Harness Assy (PL3.1.18)
■ Feed Roller Assy (PL3.2.4)
■ Registration Input Actuator
(PL3.2.11)
■ Registration Sensor (Sensor Photo)
(PL3.2.13)
■ Main Drive Assy (PL7.1.2)
■ Feed Drive Assembly (PL7.1.4)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
■ “Map 3 - SFP IP Board, LVPS, and Drive”
on page 10-8
■ “Map 4 - SFP MCU Board” on
page 10-9
■ “SFP Media Feed” on page 10-27
■ “SFP Main Drive” on page 10-28
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
■ “Map 9 - MFP MCU Board and HVPS”
on page 10-18
■ “MFP Media Feed” on page 10-40
■ “MFP Main Drive” on page 10-41
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the paper condition.
Is the paper in Tray 1 wrinkled or
damaged?
Replace with
new dry paper,
then go to step
2.
Go to step 3.
2 Does the error still occur when
printing?
Go to step 3. Complete.
3 Reload Tray 1 with new paper.
Does the error still occur when
printing?
Go to step 4. Complete.
4 Open and close the Front Cover,
making sure to latch correctly.
Does the error still occur when
printing?
Go to step 5. Complete.
5 Perform the procedure “Main Drive
Assembly” on page 4-29.
Does the Main Motor (Main Drive
Assy) operate properly?
Go to step 6. Go to step 19.
