Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-43
Error Messages and Codes
IOT Fuser Near Life
Applicable Error Code
• 010-421
Warning
To avoid possible burns, allow the Fuser Assy to cool before beginning the
procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser Assy (PL6.1.1)
■ MCU Board (SFP PL8.2.13;
MFP PL8.3.6)
■ “Map 1 - SFP Print Engine” on
page 10-6
■ “Map 4 - SFP MCU Board” on
page 10-9
■ “Map 6 - MFP Print Engine” on
page 10-15
■ “Map 9 - MFP MCU Board and HVPS”
on page 10-18
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Is the Fuser Assy installed correctly? Go to step 3. Reseat the
Fuser Assy,
then go step 2.
2 Does the error still occur when the
power is turned Off and On?
Go to step 3. Complete.
3 Replace the Fuser Assy. (page 8-10)
Does the error still occur when the
power is turned Off and On?
NOTE After replacing the Fuser, be
sure to reset the Fuser counter.
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
