Xerox WorkCentre 6505 Service Manual

3-162 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
PCI Bus# (0/1) Error Detected / PCI Bus# (0/1) Host Bridge Controller Error
/ PCI Error Messages received from Bus#0-Device# (0/1)
Applicable Error Codes
• 116-361 / 116-362 / 116-363 / 116-366 / 116-368 / 116-369
Collate Full
Applicable Error Code
• 116-721
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP PL8.1.7; MFP
PL8.1.2)
■
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Cycle the power Off, then On.
Does the error still occur?
Replace the IP
Board. (SFP,
page 8-120;
MFP,
page 8-144)
Complete.
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Cycle the power Off, then On.
Does the error still occur?
Go to step 2. Complete.
2 Check RAM Disk size settings.
Does the error occur when printing
after reducing the size setting of the
RAM Disk?
Split the
document into
blocks to
decrease the
number of
pages to be
collated.
Complete.
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
