Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-163
Error Messages and Codes
Fax Card Modem Error
Applicable Error Code
• 134-211
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (MFP PL8.1.2)
■ FAX Board (MFP PL8.1.5)
—
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Cycle the power Off, then On.
Does the error still occur when faxing?
Go to step 2. Complete.
2 Reseat the FAX Board. (page 8-143)
Does the error still occur when faxing?
Go to step 3. Complete.
3 Replace the FAX Board. (page 8-143)
Does the error still occur when faxing?
Replace the IP
Board. (MFP,
page 8-144)
Complete.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
