Xerox WorkCentre 6505 Service Manual

3-66 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
SMB Logging Error
Applicable Error Codes
• 031-521 / 031-522
SMB Server Error/DNS Error/In SMB scan, server connection error
Applicable Error Codes
• 031-523 / 031-526 / 031-528
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (MFP PL8.1.2) ■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the customer operation
Did the customer input the login name
and the password correctly?
Go to step 2. Try the login
again.
2 Check the access limitation
Does the system administrator set the
access limit number?
Ask to the
system
administrator.
Go to step 3.
3 Check the printer setting
Is Default Settings > Scan Defaults >
Scan To Network set to Computer?
Go to step 4. Set to
Computer.
4 Use the “ping” command to check the
network connection.
Are the printer and the PC connected
to the network?
Replace the IP
Board.
(page 8-144)
Check the
network.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (MFP PL8.1.2) ■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
