General Troubleshooting
NVM Settings
These are specialized tests for transferring settings data back and forth between
the MCU non-volatile memory the IP Board non-volatile memory.
Edit NVM
Caution
Editing the data in non-volatile memory can affect printer operation. Field use
of this test is not recommended.
Save NVM to ESS
Use this test to preserve NVM settings when replacing the MCU Board.
1. Enter Service Diagnostics (page 4-8).
2. Run the Save NVM to ESS test: Engine Diag > NVM Settings> Save NVM to
ESS.
3. Press OK to perform the NVM Save.
4. When the NVM Save is complete, press the Cancel button several times to
display Engine Diag, then exit Service Diagnostics.
Load NVM from ESS
Use this test to restore NVM settings after replacing the MCU Board.
1. Enter Service Diagnostics (page 4-8).
2. Run the Load NVM from ESS test: Engine Diag > NVM Settings> Load NVM
from ESS.
3. Press OK to perform the NVM Save.
4. When the NVM Save is complete, press the Cancel button several times to
display Engine Diag, then exit Service Diagnostics.
Initialize Slave
Field use of this test is not recommended.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
