Xerox WorkCentre 6505 Service Manual

1-18 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
General Information
Scanning Specifications
Characteristic Specifications
Scanning Mode
■ Platen Mode: Scan document using the document glass
■ Constant Velocity Transport (CVT) Mode: Scan
document via the Automatic Document Feeder (ADF)
Maximum Scan Size
■ Platen Mode: 215.9 mm x 297 mm (8.5 in. x 11.7 in.)
■ CVT mode; 215.9 mm x 355.6 mm (8.5 in. x 14 in.)
Media Size
Minimum
■ Fast Scan Direction: 148 mm (5.8 in.)
■ Slow Scan Direction; 210 mm (8.3 in.)
Maximum
■ Fast Scan Direction: 215.9 mm (8.5 in.)
■ Slow Scan Direction: 355.6 mm (14.0 in.)
USB Scanning
Resolution 1200 x 1200 dpi optical, up to 9600 dpi interpolated
■ Scan Interface
■ File Formats
TWAIN/ WIA 2.0
BMP, JPG, PDF, TIFF
Network Scanning
Resolution Up to 600 dpi
Color Mode Color, Black & White
Original Type Text, Photo, Mixed
File Format JPG, PDF, TIFF
Lighter/Darker 7 levels
Sharpness 3 levels
Contrast 3 levels
Auto Exposure Off, Normal, Higher (1, 2)
Scan to Desktop via
SMB
Up to 6 SMB servers
Scan to FTP Up to 6 FTP servers
Scan to E-mail Yes (no individual user log in)
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
