Xerox WorkCentre 6505

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-43
Wiring
MFP Xerographics
MCU Board
PL8.2.13
P/J42
5
6
7
8
9
10
PHD XPRO Harness Assembly
PL9.1.11
Left Side Harness Assembly
PL3.1.18
Imaging Unit
PL4.1.21
P/J422
6
5
4
3
2
1
+3.3VLD
DATA
CLOCK
+3.3VDC
SG
+3.3VDC
CLOCK
DATA
SG
+3.3VLD
1
2
3
4
PHD
EEPROM
P/J144
4
3
2
1
SG
+5VDC
HUMI.
TEMP.
P/J20
1
2
3
4
P/J201
4
3
2
1
EEPROM Board
PL8.2.16
Humidity
Sensor
PL8.2.7
LVPS Main Harness Assembly
PL9.1.3
ERASE Y/M/C ON (L) +3.3VDC
ERASE K ON (L) +3.3VDC
+3.3VDC
P/J14
15
16
17
P/J141
3
2
1
Erase LED
Assembly
PL4.1.8
1
2
3
4
Left Side Harness Assembly
PL3.1.18
Transfer Assembly
PL6.1.7
5
4
3
2
1
+5VDC
ADC SENSOR
LED REM
ADC V MONI
5
1
2
3
4
5
SG
P/J2811P/J281P/J28
5
4
3
2
1
ADC Sensor
s6505-461
+3.3VDC
+3.3VDC
+5VDC
+5VDC
to ROS
