Xerox WorkCentre 6505 Service Manual

10-26 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
SFP LVPS
MCU Board
PL8.2.13
Power
Control
Fan
Control
1
3
P/J44
I/L +24VDC
1
2
P/J502
1
2
3
P/J503
LINE
NUT
Fan
PL8.1.1
FAN +24VDC
FAN ALARM
SG
I/L +24VDC
P/J501 P/J14
+3.3VDC
+5VDC
1
2
3
4
5
6
7
8
9
10
11
12
13
P/J15
1
2
SG
14
13
12
11
10
7
8
9
6
5
4
3
2
4
2
1
2
3
PL8.2.5
SG
+5VDC
R/H COVER OPEN
SG
+3.3VDC
SG
1
2
2
1
P/J29P/J291
Switch
PL5.1.9
LV TYPE
FSR ENB
HEAT 1
DEEP SLEEP
SG
24V OFF
FAN STOP
FAN LOW
FAN ALARM
14
1
I/L OPEN
Power Switch Harness Assembly
PL8.2.9
P/J48
s6500-457
LVPS
PL8.2.1
LVPS2 Harness Assembly
PL9.1.3
LVPS Main Harness Assembly
PL9.1.3
PL5.1.27
Interlock
+24VDC
3
1
Interlock Harness Assembly
Side Switch
Harness Assembly
FG
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
