Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-5

Wiring

SFP Optional Feeder Plug/Jack Designators

P/J Map Coordinates Remarks

273 5 D-184 Connects Option Feeder (Tray Harness) and Printer

419 5 C-179 Connects Feeder Board and Tray Harness

420 5 D-179 Connects Feeder Board and Tray Comp Harness

421 5 C-180 Connects Feeder Board and Tray Comp Harness

422 5 D-180 Connects Feeder Board and Tray Motor Harness

4201 5 H-181 Connects Turn Clutch and Tray Comp Harness

4202 5 D-185 Connects Paper Path Sensor and Tray Comp Harness

4211 5 F-180 Connects Feed Solenoid and Tray Comp Harness

4212 5 F-185 Connects No Paper Sensor and Tray Comp Harness

4221 5 E-179 Connects Sub Motor (Option Feeder Motor) and Tray

Motor Harness
