Xerox WorkCentre 6505 Service Manual

2-58 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Theory of Operation
Optional Feeder
s6500-092
Feed Motor
Idle Gear 86-20z
Idle Gear 40z
Turn Clutch
Idle Gear 28-20z
Idle Gear 36z
Idle Gear 25z
Idle Gear 25z
Idle Gear 22-33z
Feed Gear Assembly
Feed Solenoid
Rubber Registration Gear
Metal Registration Gear
[ Rubber Turn Roller ]
[ Feed Roller ]
[ Metal Turn Roller ]
