Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 2-57
Theory of Operation
s6500-073
Front
Fuser
Duplex Unit
Exit Gear
Cont Clutch Gear
Out Clutch Gear
Idler Gear 24
Gear D1
SN Idler Gear
SN Idler Gear
Idler Gear 18
Exit Motor
Duplex Motor
Exit Roller
[ Duplex Roller Assembly ]
[ Duplex Roller
Assembly ]
Duplex Roller Gear
Duplex Roller Gear
Delay Idler Gear
Delay Idler Gear
Duplex Idler Gear
Idler Gear 16
Gear E1
Duplex Clutch
Clutch Idler Gear
Duplex Output Gear

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
