1-8 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
General Information
Internal View, SFP
1. Fu s e r
2. I m a g i n g U n i t
3. Front Cover and Duplex Unit release.
4. D u p l e x U n i t
5. Transfer Belt (Tray 1 removed so the Transfer Belt folds down completely).
s6500-005
1
2
3
4
5
