Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-111
Error Messages and Codes
Option Feeder Motor Failure
Applicable Error Code
• 072-216
6 Check the Option Harness Assy for
continuity.
Disconnect P/J27 from the MCU
Board.
Disconnect P/J273 from the Tray
Harness Assy.
Is each cable of P/J27 <=> P/J273
continuous?
Go to step 7. Replace the
Option
Harness Assy.
7 Check after replacing the Optional
Feeder.
Replace the Replace the Optional
Feeder. (page 8-167)
Does the error still occur when the
power is turned Off and On?
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Motor Subassembly (PL12.2.98)
■ Feeder Board (PL12.2.1)
■ Tray Motor Harness Assy
(PL12.2.2)
■ Optional Feeder (PL12.1.99)
■ “Map 5 - SFP Optional Feeder” on
page 10-10
■ “SFP Option Feeder” on page 10-35
■ “Map 10 - MFP Optional Feeder” on
page 10-19
■ “MFP Option Feeder” on page 10-50
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Does the error still occur when the
power is turned Off and On?
Go to step 2. Complete.
2 Check the connectors of the Motor
Subassembly for connection.
Check the connections between the
Feeder Board and Motor Subassembly.
Are P/J422 and P/J4221 connected
correctly?
Go to step 4. Reconnect the
connector(s) P/
J422 and/or P/
J4221
correctly, then
go to step 3.
3 Does the error still occur when the
power is turned Off and On?
Go to step 4. Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
To Next Page
