Xerox WorkCentre 6505 Service Manual

3-74 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
DFAX Password Error
Applicable Error Code
• 033-517
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MFP IP Board (ESS) (MFP PL8.1.2) ■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1Check the password.
Check the password of Fax/Scanner
Lock in the Panel Lock menu.
Is the password correct?
Go to step 2. Set the correct
password.
2 Check the printer setting
In the Admin menu, set Secure
Settings… > Panel Lock > Panel Lock
Set to Disable.
Does the error still occur when
executing the D-FAX?
Replace the IP
Board.
(page 8-144)
Set Panel Lock
Set to Enable.
If the error
occurs again,
replace the IP
Board.
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
