3-40 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
IOT Fuser Life Over
Applicable Error Code
• 010-351
To avoid possible burns, allow the Fuser Assy to cool before beginning the
procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser Assy (PL6.1.1)
■ Fuser Harness Assy (PL6.1.2)
■ MCU Board (SFP PL8.2.13;
MFP PL8.3.6)
■ “Map 1 - SFP Print Engine” on
page 10-6
■ “Map 4 - SFP MCU Board” on
page 10-9
■ “Map 6 - MFP Print Engine” on
page 10-15
■ “Map 9 - MFP MCU Board and HVPS”
on page 10-18
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the life counter value of the
Fuser Assy.
Does the life counter value show the
near of the end?
Replace the
Fuser Assy.
(page 8-10)
After replacing
the Fuser, be
sure to reset
the Fuser
counter.
Go to step 2.
2 Check after resetting the Fuser Assy.
Reseat the Fuser Assy.
Does the error still occur when the
power is turned Off and On?
Go to step 3. Complete.
3 Check after replacing the Fuser Assy.
Replace the Fuser Assy. (page 8-10)
Does the error still occur when the
power is turned Off and On?
NOTE: After replacing the Fuser, be
sure to reset the Fuser counter.
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.
