Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 4-73
General Troubleshooting
Abnormal Noises
Abnormal Noise When Power is Turned On
Initial Actions
• Check for obstructions or debris in the media path.
•Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Imaging Unit, PL4.1.21
Fuser, PL6.1.1
Transfer Belt, PL6.1.7
Sub Drive Assembly, PL7.1.1
Main Drive Assembly, PL7.1.2
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Test the Main Drive (page 4-29):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Go to step 2. Go to step 5.
2 Reseat the Imaging Unit.
Test the Main Drive (page 4-29):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Go to step 3. Complete
3 Check for proper Transfer Belt
installation.
Test the Main Drive (page 4-29):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Go to step 4. Complete

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
