Xerox WorkCentre 6505 Service Manual

3-44 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
Image Processor Board Error
Applicable Error Codes
• 016-500 / 016-501 / 016-502
• 017-979 / 017-980 / 017-986 (MFP Only)
• 033-502 / 033-520 / 033-521 / 033-522 / 033-523 / 033-524 / 033-525 /
033-526 (MFP Only)
• 116-315 / 116-317 / 116-323 / 116-324 / 116-326 / 116-327 116-328 / 116-
343 / 116-350 / 116-390 /
• 116-210 / 116-364 / 116-396 / 116-987 (MFP Only)
• 117-315 / 117-331 / 117-344 / 117-362 / 117-363 / 117-365 (MFP Only)
• 123-314 (MFP Only)
• 131-398 / 131-399 (MFP Only)
• 133-259 / 133-260 / 133-261 / 133-269 / 133-271 / 133-272 / 133-273 /
133-274 / 133-276 / 133-277 / 133-281 / 133-282 / 133-283 / 133-286 /
133-287 / 133-288 / 133-289 (MFP Only)
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP PL8.1.7; MFP
PL8.1.2)
■ “Map 3 - SFP IP Board, LVPS, and Drive”
on page 10-8
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Does the error still occur when the
power is turned Off and On?
Replace the
Processor
Board. (SFP
page 8-120;
MFP
page 8-144.)
Complete.
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
