Xerox WorkCentre 6505 Service Manual

3-160 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
IOT Belt Unit Life Over
Applicable Error Code
• 094-911
ESS DIMM Slot RAM R/W Check Fail / ESS DIMM Slot RAM Error
Applicable Error Codes
• 116-316 / 116-320
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Transfer Belt (PL6.1.7)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
■ “Map 1 - SFP Print Engine” on
page 10-6
■ “Map 4 - SFP MCU Board” on
page 10-9
■ “Map 6 - MFP Print Engine” on
page 10-15
■ “Map 9 - MFP MCU Board and HVPS”
on page 10-18
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Does the error still occur when the
power is turned Off and On?
Go to step 2. Complete.
2 Using Printer Diagnostics, check the
life count value of the Transfer Unit:
Printer Diag > Parameter > Life DTB
Waste > Read.
Do the values returned indicate near
end-of-life (100 K)?
Does the life counter value indicate
near end of life?
After replacing
the Transfer
Belt
(page 8-112),
initialize the
life counter
value: Printer
Diag >
Parameter >
Life DTB
Waste > Read
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP PL8.1.7; MFP
PL8.1.2)
■ Optional Memory Card (SFP
PL8.1.15; MFP PL8.1.4)
—
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
