Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-55
Error Messages and Codes
Disk Full
Applicable Error Code
• 016-982
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP PL8.1.7; MFP
PL8.1.2)
■ Optional Memory Card (SFP
PL8.1.15; MFP PL8.1.4)
■ “Map 3 - SFP IP Board, LVPS, and Drive”
on page 10-8
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the file data in the printer.
Print or clear the stored files and data
at the printer memory.
Does the error still occur when
printing?
Go to step 2. Complete.
2 Print a small size file (like a Windows
test page).
Does the error still occur when
printing?
Go to step 3. Add an
Optional
Memory Card,
or divide
the printing
job.
3 Is the customer using the
recommended memory card?
Go to step 4. Replace to the
recommended
memory card.
4 Reseat the Optional Memory Card.
Does the error still occur when turning
on the power?
Go to step 5. Complete.
5 Replace the Optional Memory Card.
Does the error still occur when turning
on the power?
Replace the IP
Board. (SFP,
page 8-120;
MFP,
page 8-144)
Complete.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
