Xerox WorkCentre 6505 Service Manual

8-4 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Service Parts Disassembly
Notations in the Disassembly Text
• The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
•The notation “PLX.X.X” indicates the component is listed in the Parts List.
• Arrows in an illustration show direction of movement when removing or
replacing a component.
• The notation “(tap, plastic, 10 mm)” or “(metal, 6 mm)” refer to the type of
screw being removed.
Replacement Note
Provides information specific to the replacement of parts or assemblies.
Imaging Unit
Toner Cartridges
Fuser Assembly
s6500-505
Paper Tray
Separator Roller
Feed Roller
ADF Feed Roller
Assembly
ADF Separator Pad
Assembly
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
