Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 1-23
General Information
Operating Mode
Mode Condition Description
Running Mode There are three running modes:
■Print mode – the print engine operates
for printing and report printing in the
SFP, and for printing, copying, Fax
received printing, and report printing in
the MFP.
■Scan mode (MFP only) – the IIT is
operating for copy, local, and network
scanning, and for Fax sending.
■Fax communication mode (MFP only) –
Fax sending/receiving is in progress.
Exposure The Laser Unit Motor runs at the
operating speed.
Recording The system is operating.
Fusing Maintained at operating temperature.
IIT Scanner or ADF is in operation, scanning
lamp is on.
Cooling Fan The fan operates at high speed.
Control Panel
Operation
LCD - Backlight: On
LED - Ready LED is On.
Ready Mode The printer is in standby status, ready to
run.
Exposure The system is at Pause.
Recording The system is at Pause.
Fusing The system keeps the standby
temperature.
IIT The Scanner and ADF are in a standby
status, ready to run.
Cooling Fan The fan operates at low speed.
Control Panel
Operation
LCD - Backlight: On
LED: If printer is online, Ready LED is On.
Power Saver
Mode (Deep
Sleep)
The printer enters Power Saver mode
when it has not received print data for the
specified time.
Exposure The system is at Pause.
To Next Page
