Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-93
Error Messages and Codes
Scanner Error
Applicable Error Code
• 062-320
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IIT Sub Assembly (MFP PL10.1.11)
■ IP Board (ESS) (MFP PL8.1.2)
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
■ “Scanner - IIT Sub-Assembly” on
page 10-49
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the file data in the printer.
Print or clear the stored files and data
at the printer memory.
Does the error still occur when
scanning?
Go to step 2. Complete.
2 Check the setting at Defaults Settings
> Scan Defaults… > Resolution.
Is it set to 600 x 600?
Set to the
default value.
Go to step 3.
3 Check the setting at Defaults Settings
> Scan Defaults… > Color.
Is it set to Color (Photo)?
Set to Color
(Photo).
Go to step 4.
4 Replace the IIT Sub Assembly.
(page 8-195)
Does the error still occur when turning
the power Off and On?
Replace the IP
Board.
(page 8-144)
Complete.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
