Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-49
Error Messages and Codes
PDL Error
Applicable Error Code
• 016-720
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP
PL8.1.7; MFP
PL8.1.2)
■ “Map 3 - SFP IP Board, LVPS, and Drive” on page 10-8
■ “Map 8 - MFP LVPS, IP Board, and Drive” on
page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the cable between the
Printer and PC (or Printer and Hub).
- For local printer: USB cable
(USB2.0)
- For network printer: Ethernet
cable (10Base-T/100Base-TX /
1000Base-T)
Does the cable meet the
specifications?
Go to step 2. Use a cable that
meets the
specifications.
- For local printer:
USB cable
(USB2.0)
- For network
printer: Ethernet
cable(10Base-T/
100Base-TX /
1000Base-T)
2 Plug and unplug the cable. (USB
cable or I/F cable)
Does the error still occur when
printing?
Go to step 3. Complete.
3 Replace the cable. (USB cable or
I/F cable)
Does the error still occur when the
power is turned Off and On?
Replace the IP
Board. (SFP,
page 8-120;
MFP,
page 8-144)
Complete.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
