Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-27
Wiring
SFP Media Feed
MCU Board
PL8.2.13
9
10
11
3
2
1
PULL UP +3.3VDC
SG
PAPER EMPTY SENSED (L) +3.3VDC
Tray 1 No Paper
Sensor
PL3.2.13
P/J234
I/L +24VDC
CST FEED CL ON (L) +24VDC
2
1
1
2
1
2
Feed Solenoid
PL3.1.11
P/J231
P/J23
6
7
8
PAPER EMPTY SENSED (H) +3.3VDC
SG
P/J233
3
2
1
PULL UP +3.3VDC
Manual Feed No Paper
Sensor
PL3.2.13
3
4
5
REGI SENSED (L) +3.3VDC
SG
3
2
1
PULL UP +3.3VDC
Registration Sensor
PL3.2.13
P/J232
s6500-458
+3.3VDC
+24VDC
