Xerox WorkCentre 6505 Service Manual

10-48 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
ADF
IP Board
PL8.1.2
JADF1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
+24V DC
SOL_OUT
xSCAN_A_ADF
SCAN_A_ADF
SCAN_B_ADF
xSCAN_B_ADF
+5V DC
S_ENTRY_N
S_FEED_N
S_COVER_N
SG
S_FEED2_N
S_COVER2_N
SG
ADF Assembly
PL10.1.3
Connector Board
s6500-487
1
2
3
4
5
6
7
8
9
10
11
12
13
14
+24VDC
+5VDC
1
2
3
JDFM1
JCV1
1
2
3
4
ADF Motor
ADF
Cover
Sensor
M
1
2
3
JDES1
ADF
Document
Sensor
1
2
3
JDS1
ADF
Feed
Sensor
A
/A
B
/B
+3.3VDC
+3.3V
P/J1003
ADF Harness
PL10.1.2
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
