Xerox WorkCentre 6505 Service Manual

10-18 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
Map 9 - MFP MCU Board and HVPS
A
147
148
149
150
151
152
153
154
155
156
157
158
159
160
146
BCDEFGHIJ KL
s6500-434
192
422
161
191
182
181
144
11
42
22
21
24
26
15
14
17
101*
31
19
18
29
40 41 10
16
27
20
23
28
: Not Connected
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
