10-42 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
MFP Laser Unit
MCU Board
PL8.2.13
P/J40 P/J411
1
2
3
4
5
6
SG
I/L +24VDC
ROS MOT CLK
SOS
7
8
9
10
11
12
LD ERR
PCONT
SG
V REF K
V REF C
V REF M
V REF Y
ROS MOT ON
Laser RE Harness Assembly
PL4.1.22
LOCK
ROS MOT ON
SG
+24VDC
+5VDC
SOS
SG
CLK
Laser Unit
PL4.1.1
ROS Motor
SOS Board
s6500-460
13
14
ENB
15
15
14
13
12
11
1
2
3
4
5
10
9
8
7
6
5
1
2
3
5
4
3
2
1
3
2
1
4
3
2
1
SG
+3.3V LD
Interlock
+24VDC
P/J41 P/J412
1
2
3
4
5
6
DATA K
SG
DATA C
SG
7
8
DATA M
SG
DATA Y
SG
Laser Video Harness Assembly
PL4.1.23
8
7
6
5
4
3
2
1
from Xerography
