Xerox WorkCentre 6505 Service Manual

10-36 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
SFP Duplex Unit
MCU Board
PL8.2.13
P/J27
B1
B2
B3
B4
B5
B6
B7
B8
B9
P/J272
Duplex Relay
Harness Assembly
PL1.2.13
Duplex Harness Assembly
PL11.1.14
Txd
Rxd
DUP-HOT
+3.3VDC
SG
I/L +24VDC
I/L +24VDC
SG
SG
P/J601
9
10
8
7
6
5
4
3
2
10
9
8
7
6
5
4
3
2
1
2
3
4
5
6
7
8
9
P/J604
Duplex Board
PL11.1.16
P/J602
4
3
2
1
Exit Drive
Assembly
PL11.2.2
DUP UP_A
DUP UP_XA
DUP UP_B
DUP UP_XB
I/L +24VDC
DUP CL ON (L) +24VDC
1
2
Duplex Clutch
PL11.2.2
s6500-467
Interlock
+24VDC
+3.3VDC
B10
B11
SG
1
1
10
P/J271
9
10
8
7
6
5
4
3
2
1
2
3
4
5
6
7
8
9
110
Interlock
+24VDC
Interlock
+24VDC
+3.3VDC
M
P/J603
5
4
3
2
1
Duplex Drive
Assembly
PL11.2.5
DUP DOWN_A
DUP DOWN_XA
DUP DOWN_XB
DUP DOWN_B
M
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
