Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-117
Error Messages and Codes
IOT Regi OFF Jam
Applicable Error Code
• 077-101
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Cassette Assy 250 (PL2.1.1)
■ Separator Holder Assy (PL2.1.5)
■ Drive Clutch and Regi Bearing Kit
(PL3.1.97)
■ Feeder Assy (PL3.1.98)
■ Feed Solenoid Kit (PL3.1.99)
■ Left Side Harness Assy (PL3.1.18)
■ Feed Roller Assy (PL3.2.4)
■ Regi Roller Actuator (PL3.2.8)
■ Registration Input Actuator
(PL3.2.11)
■ Registration Sensor (Sensor Photo)
(PL3.2.13)
■ Main Drive Assy (PL7.1.2)
■ Feed Drive Assembly (PL7.1.4)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
■ “Map 3 - SFP IP Board, LVPS, and Drive”
on page 10-8
■ “Map 4 - SFP MCU Board” on
page 10-9
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
■ “Map 9 - MFP MCU Board and HVPS”
on page 10-18
■ “SFP Media Feed” on page 10-27
■ “SFP Main Drive” on page 10-28
■ “MFP Media Feed” on page 10-40
■ “MFP Main Drive” on page 10-41
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the paper condition.
Is the paper in Tray 1 wrinkled or
damaged?
Replace the
paper with a
new and dry
one, then go to
step 2.
Go to step 3.
2 Does the error still occur when
printing?
Go to step 3. Complete.
3 Reload new paper in Tray 1.
Does the error still occur when
printing?
Go to step 4. Complete.
4 Check the Front Cover for latching.
Open and close the Front Cover, and
then latch correctly.
Does the error still occur when
printing?
Go to step 5. Complete.
To Next Page
