Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-11
Wiring
MFP Plug/Jack Designations
MFP Print Engine P/J Designators
MFP Print Engine Plug/Jack Designators
P/J Map Coordinates
Remarks
2 7 D-121 Connects Front USB Assy and Front USB Harness Assy
10 9 I-156 Connects MCU Board and IP Board Harness Assy
11 9 I-156 Connects MCU Board and IP Board Video Harness Assy
14 9 H-157 Connects MCU Board and LVPS Main Harness Assy
15 9 H-156 Connects MCU Board and LVPS Main Harness Assy
16 9 I-158 Connects MCU Board and HVPS Harness Assy
17 9 H-157 Connects MCU Board and Fuser Harness Assy
18 9 H-158 Connects MCU Board and Toner Motor Harness Assy
19 9 H-158 Connects MCU Board and Toner Motor Harness Assy
20 9 J-158 Connects MCU Board and Left Side Harness Assy
21 9 J-157 Connects MCU Board and Main Motor Harness Assy
22 9 J-157 Connects MCU Board and Sub Motor Harness Assy
23 9 J-158 Connects MCU Board and Left Side Harness Assy
24 9 J-158 Connects MCU Board and K-Solenoid Harness Assy
26 9 J-158 Connects MCU Board and K-Sensor Harness Assy
27 9 I-158 Connects MCU Board and Option Harness
28 9 J-158 Connects MCU Board and Left Side Harness Assy
29 9 I-158 Connects MCU Board and Toner Door Switch Harness
31 9 H-157 Connects MCU Board and Toner CRUM Harness Assy
40 8 D-143 Connects LVPS and IP Board Power Harness
40 9 I-156 Connects MCU Board and Laser Unit RE Harness
41 9 I-156 Connects MCU Board and Laser Unit Video Harness
42 9 J-157 Connects MCU Board and PHD XPRO Harness Assy
44 8 D-143 Connects LVPS and Interlock Switch
47 8 B-143 Connects LVPS and Fuser Harness Assy
48 8 B-142 Connects LVPS and Inlet Switch Assy
101 9 I-157 Not Connect (Debug only)
141 6 G-108 Connects Erase LED Assy and LVPS Main Harness Assy
144 9 F-152 Connects EEPROM Board and PHD XPRO Harness Assy
161 9 F-153 Connects HVPS and HVPS Harness Assy
