Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-35
Error Messages and Codes
Error Code Troubleshooting
IOT Option Feeder I/F Failure
An Option Feeder communication failure is detected.
Applicable Error Code
• 004-310
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Option Harness Assy (PL3.1.20)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
■ Optional Feeder Assy (PL12.1.3)
■ Tray Harness Assy (Optional
Feeder Harness) (PL12.3.23)
■ “SFP Optional Feeder Plug/Jack
Designators” on page 10-5
■ “Map 5 - SFP Optional Feeder” on
page 10-10
■ “MFP Optional Feeder Plug/Jack
Designators” on page 10-14
■ “Map 10 - MFP Optional Feeder” on
page 10-19
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Is the Optional Feeder installed
correctly?
Go to step 3. Reseat the
Optional
Feeder, then
go to step 2.
2 Does the error still occur when
printing?
Go to step 3. Complete.
3 Are the connections between the MCU
Board and Option Feeder Board (P/
J27, P/J273, and P/J419) connected
securely?
Go to step 5. Reconnect the
Plugs/Jacks
securely, then
go to step 4.
4 Does the error still occur when
printing?
Go to step 5. Complete.
5 Check the Optional Feeder Harness for
continuity.
Disconnect P/J419 from the Option
Feeder Board and P/J273 from the
Option Harness Assy.
Is each cable of P/J419 <=> P/J273
continuous?
Go to step 6. Replace the
Optional
Feeder Harness
(page 8-179).

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
