2-64 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual

Theory of Operation

Scanning on Document Glass

The Scanhead travels to read the document. The Scanhead includes the following

components:

•Exposure Lamp that illuminates light onto the document,

• CCD Image Sensor that reads light reflected from the document, and

• Lenses and mirrors comprising the light path for the optical image.

s6500-080

Scanhead

Scanner Home Position Sensor

Carriage Motor
