Xerox WorkCentre 6505 Service Manual

4-70 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
General Troubleshooting
+24 VDC Interlock Switch
The Interlock Switch disables +24 V to the electromechanical components when
the Front Cover is open.
Initial Actions
• Check the switch actuator located on the Left front holder.
• Check for obstructions or debris blocking switch motion.
•Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ LVPS, PL8.2.1
■ Interlock Harness, PL8.2.5
■ “SFP LVPS” on page 10-26
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Interlock Harness for
continuity.
1. Disconnect P/J44.
2. Check continuity between P/J44-1 <=>
P/J44-3.
Is the circuit continuous when the switch
is closed?
Replace the
LVPS
(page 8-124.
Replace the
Interlock
Harness
(page 8-125)
.
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
