Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-71
Error Messages and Codes
CODEC Error
Applicable Error Code
• 033-501
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MFP IP Board (ESS) (MFP PL8.1.2)
■ IIT Sub Assembly (MFP PL10.1.11)
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
■ “Scanner - IIT Sub-Assembly” on
page 10-49
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the firmware version.
Is the firmware the latest version?
Go to step 2. Update the
firmware
(“Firmware
Update” on
page A-16),
then go to step
2.
2 Check after replacing the IP Board
Replace the IP Board. (page 8-144)
Does the error still occur when the
power is turned Off and On?
Replace the IIT
Sub Assembly.
(page 8-195)
Complete.
