Xerox WorkCentre 6505 Service Manual

6-6 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Adjustments and Calibrations
Calibrations
Initializing Print Meter
This process initializes the Print Meter.
1. On the Control Panel, press Menu.
2. Press the Up or Down arrow to find Admin Menu. Press the OK button.
3. Press the Up or Down arrow to find Maintenance Mode. Press OK.
4. Press the Up or Down arrow to find Init PrintMeter. Press OK.
5. Are you sure? message is displayed. Press OK to start the process.
6. Initialized message is displayed. The Maintenance Mode - Init PrintMeter
menu is displayed when the process is completed.
Initializing NVM (NVRAM)
This process initializes the settings stored in the NVRAM except for the network
settings. The NVRAM is a non-volatile memory that stores the printer settings even
after the power is turned Off. After executing this function and restarting the
printer, all the menu parameters are reset to their default values.
1. On the Control Panel, press Menu.
2. Press the Up or Down arrow to find Admin Menu. Press OK.
3. Press the Up or Down arrow to find Maintenance Mode. Press OK.
4. Press the Up or Down arrow to find Initialize NVM. Press OK.
5. Are you sure? message is displayed. Press OK to start the process.
6. Initializing... --> Initialized messages are displayed.
7. The Maintenance Mode - Initialize NVM menu appears when the process is
completed.
8. Turn the printer power Off and back On.
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
