Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 2-59
Theory of Operation
s6500-075
Front
: Indicates The Engagement Of Gears.
Feed Gear
Idle Gear 28-20z
Idle Gear 40z
Idle Gear 36z
Idle Gear 25z
Idle Gear 25z
Idle Gear 86-20z
Feed Motor
Turn Clutch
Rubber Registration Gear
Metal Registration Gear
Feed Solenoid
Feed Roller
Idle Gear 22-33z
