Xerox WorkCentre 6505 Service Manual

3-96 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
6 Check the Feed Drive Assembly for
operation.
Perform the procedure “Registration
Clutch” on page 4-33
Do the Feed, Regi, and Regi Metal
Rollers rotate properly?
Go to step 7. Reseat or
replace the
Feed Drive
Assembly.
(page 8-117)
7 Does paper feed from Tray 1? Go to step 12. Go to step 8.
8 Reset the Tray 1 Side and End Guides,
and return the tray to the printer.
Does the error still occur when
printing?
Go to step 9. Complete.
9 Remove Tray 1 from the printer.
Is the Separator Holder Assy free of
contamination and/or damage, and
does it rotate smoothly?
Go to step 10. Replace the
Separator
Holder Assy.
(page 8-6)
10 Remove Tray 1 from the printer.
Is the Feed Roller Assy free of
contamination and/or damage, and
does it rotate smoothly?
Go to step 11. Replace the
Feed Roller
Assy.
(page 8-9)
11 Perform the procedure “Tray 1 Feed
Solenoid” on page 4-34.
Does the Tray 1 Feed Solenoid operate
properly?
Replace the
Cassette Assy
250. (Parts List
2.1 Tray 1.)
Go to step 22.
12 Does the paper leading edge stop
before the Regi Roller Assy and Regi
Metal Roller?
Go to step 13. The paper
leading edge
stops past the
Regi Roller Assy
and Regi Metal
Roller; go to
step 16.
13 Check the paper path between the
Feed Roller Assy and Regi Roller Assy.
Are there any obstacles in the paper
path?
Remove the
obstacles from
the paper
transfer path.
Go to step 14.
14 Perform the procedure “Registration
Sensor” on page 4-22.
Does the number on the screen
increase by one, when the actuator
(Registration Input Actuator) is
operated?
Go to step 15. Go to step 26.
15 Remove the Lower Chute Assembly
(page 8-84; PL3.2.27) to check the
shape and operation of the
Registration Input Actuator (PL3.2.11).
Are the shape and operation normal?
Go to step 16. Reseat the
Registration
Input Actuator.
If broken or
deformed,
replace it.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
