Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-23
Error Messages and Codes
062 790 Copier Error
Last Sheet not Copied
Press Ok Button
<Copy Limit>
Unable to continue due to copy
limitation.
page
94
071 100 Jam at Tray 1
Check Tray 1.
Open/Close Front Cover.
<IOT Tray1 Misfeed JAM>
The Registration Sensor is not turned on
within the specified time after feeding a
paper from Tray 1.
page
95
072
This code is given when the Optional 250 Sheet Feeder is installed.
100 Jam at Tray 2
Check Tray 2
Open/Close Front Cover.
<IOT Tray2 Misfeed JAM>
The Paper Path Sensor of Tray 2 is not
turned on within the specified time after
feeding a paper from Tray 2.
page
100
101 Jam at Tray 2
Open Tray 2
Open/Close Front Cover.
<IOT Feeder 2 JAM>
A jam has been detected between the
Registration Sensor and the Paper Sensor
of Tray 2.
page
105
This code is given when the Optional 250-Sheet Feeder is installed.
215 250 Feeder Error
Error 072-215
Restart Printer
<IOT Feeder Configuration Failure>
Option Sheet Feeder Configuration error
is detected.
page
110
216 Motor Error
Error 072-216
Restart Printer
<Option Feeder Motor Failure>
Option Feeder Motor failure is detected.
page
111
900 Jam at Tray 1 or 2
Open Tray 1 or 2
Open Front Cover
<IOT Remain Option Feeder JAM>
Paper remains at the Paper Path Sensor
of Tray 2.
page
112
075 101 Jam at Front Cover
Open Front Cover
and Remove Paper
<IOT SSF Insert JAM>
Manual Feed No Paper Sensor detects
when a paper is inserted from Manual
Feed slot.
page
113
102 Jam at Manual Feed slot
Remove Paper from
Manual Feed slot.
Open/Close Front Cover.
<IOT SSF Paper Pullout JAM>
Though it tried to feed a paper from
Manual Feed slot, the paper was not
loaded or it was pulled out forcibly from
Manual Feed slot.
page
113
923 Reseat Paper in
the Manual Feed slot
<Waiting for reseat paper of SSF>
Wait for the paper in the Manual Feed
slot to be reseated.
page
113
077 100 Jam at Front Cover
Open Front Cover
and Remove Paper
<IOT Regi On early JAM>
Paper remains at the paper transfer path
between Tray 1 and the Registration
Sensor.
page
115
101 Jam at Front Cover
Open Front Cover
and Remove Paper
<IOT Regi OFF Jam>
The paper does not pass through the
Registration Sensor within the specified
time.
page
117
Error Code List & Error Message Summary (continued)
Error Code
Error Message
LCD
Error Description Go To
