Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-61
Error Messages and Codes
2 Check the firmware version.
Is the firmware the latest version?
Go to step 3. Update the
firmware
(“Firmware
Update” on
page A-16),
then go to step
3.
3 Reseat the MCU Board.
Does the error still occur when the
power is turned Off and On?
Go to step 4.
Complete.
a
4 Check after replacing the MCU Board.
Replace the MCU Board. (SFP,
page 8-138; MFP, page 8-160)
Does the error still occur when the
power is turned Off and On?
Go to
“Electrical
Noise” on
page 4-79.
Complete.
a. Electrical noise could be a possible cause. Go to “Electrical Noise” on
page 4-79 to make sure.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
