Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-153
Error Messages and Codes
14 Check the Toner Motor Harness Assy
for continuity.
Disconnect J18 from the MCU Board.
Disconnect J181(Y)/J182(M)/J191(C)/
J192(K) from the DISPENSE MOTOR
(YMCK) MOT.
Is each cable of J18 <=> J181/182
continuous? or Is each cable of J19
<=> J191/192 continuous?
Go to step 15. Replace the
Toner Motor
Harness Assy.
15 Check the power to TNR (Y) MOT
(Dispenser Motor Assy).
Disconnect J18/J19 from the MCU
Board.
Is the voltage across P18P/19-3 <= >
ground on MCU Board, about +24 VDC
when the interlock switch (Interlock
Harness Assy) is pushed.
Replace the
Dispenser
Motor Assy or
Motor Frame
Assy.
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
16 Check after replacing the Toner
Cartridge (Y, M, C or K).
Replace the Toner Cartridge (Y, M, C or
K), and check that the handle is in the
lock position. (page 8-12)
Does the error still occur when the
power is turned Off and On?
Go to step 17. Complete.
17 Check after replacing the Imaging
Unit.
Replace the Imaging Unit. (page 8-7)
Does the error still occur when the
power is turned Off and On?
Go to step 18. Complete.
18 Check after resetting the Transfer Belt.
Reseat the Transfer Belt.
Does the error still occur when the
power is turned Off and On?
Replace the
Transfer Belt.
(page 8-112)
Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
