Xerox WorkCentre 6505 Service Manual

3-158 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Does the error still occur when the
power is turned Off and On?
Go to step 2. Complete.
2 Check the Toner Type.
Is XEROX Toner installed?
Go to step 3. Verify that the
non-Xerox
toner in use is
compatible
with the
Phaser 6500/
WorkCentre
6505 printers.
3 Reseat the Toner Cartridge (Y, M, C or
K), and check that the lock key is in the
lock position.
Does the error still occur when the
power is turned Off and On?
Go to step 4. Complete.
4 Replace the Toner Cartridge (Y, M, C or
K). (page 8-12)
Does the error still occur when the
power is turned Off and On?
Go to step 5. Complete.
5 Check the Toner CRUM Harness Assy
for continuity.
Disconnect J31 from the MCU Board.
Disconnect J311 (Y) from the CRUM
Connector.
Are P/J31 and P/J311(Y),P/J312(M),P/
J313(C),P/J314(K) connected
correctly?
Go to step 6. Replace the
Toner CRUM
Harness Assy
6 Reseat the MCU Board connectors.
Does the error still occur when the
power is turned Off and On?
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
