Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 4-57
General Troubleshooting
CNG Stop Select Sets the conditions for stopping CNG
transmission. Conditions:
CED&V21: When CED and V.21
preamble are detected.
CED: When CED is detected.
V21: When V.21 preamble is
detected.
G3M TX Cable
EQU
Sets the cable amplitude equalizer
value for transmission. These values
are available:
0db Equal to a cable length of 0km.
4db Equal to a cable length of 1.9km
8db Equal to a cable length of 3.6km
12db Equal to a cable length of 7.2km
G3M RX Cable
EQU
Sets the cable amplitude equalizer
value for reception (applicable to V17,
V29, and V27ter) These values are
available:
0db Equal to a cable length of 0km.
4db Equal to a cable length of 1.9km
8db Equal to a cable length of 3.6km
12db Equal to a cable length of 7.2km
G3M V34 Bit
Rate
Sets the signaling rate for the Super
G3 (V34) mode. Values range from
2400bps to 33600bps in 14 steps.
2400/4800/7200/9600/12000/
14400/16800/19200/21600/24000/
26400/28800/31200/33600
Capability V34 Sets the communication capability of
the Super G3 (V34) mode.
G3M TX Coding Sets the data encoding method for
transmission. When the encoding
method set here is not supported by
the receiving side, the receiving side's
method is adopted. Available
methods: are MH/MR/ MMR/JBIG
G3M RX Coding Sets the data encoding method for
reception. Available methods: are
MH/MR/ MMR/JBIG
BackUp Data NOTE The system data initialization does not initialize data on
EEPROM (except dial types and country codes). The
counter clear does not clear scan counter clearance on
EEPROM; it only clears counters on SRAM.
All Clear All Clear
■ (displays a list of
country)
■ Initializes system data.
■ Clears address data, etc.
■ Clears communication control data.
■ Clears history.
■ Clears counters.
Information includes:
■ User’s area
■ System area
■ Counters (in SRAM)
Number of Scan
Number of Fax sending
Number of FlashROM erase
Test Control Panel Display Test Description

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
