5-14 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Print-Quality Troubleshooting
5 Reseat all IP Board connectors.
Is the image printed correctly?
Complete Go to step 6.
6 Reseat the Laser Unit.
Is the image printed correctly?
Complete Go to step 7.
7 Check the connections between the
Laser Unit and MCU Board.
Are P/J40, P/J 41, P/J411 and P/J
412 connected correctly?
Go to step 9. Secure the
connectors,
then go to step
8.
8 Is the image printed correctly? Complete Go to step 9.
9 Replace the Imaging Unit
(page 8-7).
Is the image printed correctly?
Complete Go to step 10.
10 Replace the IP Board (page 8-120).
Is the image printed correctly?
Complete Go to step 11.
11 Replace the Laser Unit (page 8-86).
Is the image printed correctly?
Complete Replace the
MCU Board
(page 8-138).
12 Does the error persist? Replace the
HVPS
(page 8-136).
Complete
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
