Xerox WorkCentre 6505 Service Manual

5-20 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Print-Quality Troubleshooting
5 Reseat the Fuser.
Does the error persist?
Complete Go to step 6.
6 Reseat all MCU Board connectors.
Does the error persist?
Complete Go to step 7.
7 Reseat all IP Board connectors.
Does the error persist?
Complete Go to step 8.
8 Open and close the Front Cover to
reseat the Transfer Belt.
Does the error persist?
Complete Go to step 9.
9 Check the connections between the
Laser Unit and MCU Board.
Are P/J40, P/J 41, P/J411 and P/J
412 connected correctly?
Go to step 11. Reconnect the
connectors
securely, then
go to step 10.
10 Is the image printed correctly? Complete Go to step 11.
11 Replace the Imaging Unit
(page 8-7).
Does the error persist?
Complete Go to step 12.
12 Replace the Fuser (page 8-10).
Does the error persist?
Complete Go to step 13.
13 Replace the IP Board (page 8-120).
Does the error persist?
Complete Go to step 14.
14 Replace the Laser Unit (page 8-86).
Does the error persist?
Complete Go to step 15.
15 Replace the MCU Board
(page 8-138).
Does the error persist?
Replace the
HVPS
(page 8-136).
Complete
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
